FSP Group UK 5G CRPS Power Supply Unit

Power Solutions for 5G Applications

A great amount of reconstruction of hardware equipment is required by terminal applications, Macro Sites, Micro Sites, transmission networks, core networks, or cloud data centers in the age of 5G to satisfy the needs for high speed transmission and various applications of Internet of Things. In order to achieve high frequency and efficiency goal in a 5G communication environment, different 5G equipment needs power supplies with high power and small volume (namely having a high power density), and meeting the standard of intelligent power management. To satisfy the requirements of the power supply demand for the 5G market, FSP Group, always lead the trend, has been devoting a great deal of resources to develop the most complete 5G power supply products on the market. FSP Group aims to bring the clients that participate in 5G-related applications power supply solutions which satisfy every need on just one site.


Comprehensive 5G Power Solutions

FSP Group UK 5G Networking Application with Power Supply Unit

Core capabilities of FSP power solutions

  1. R&D capability to provide a standardized and intelligent power supply

    • Products possessing scalability

    • Products possessing digital/communication functions

    • High power density

    • High efficiency

    • Anti-harsh environment design

  2. Digitized product design which enables a quick supply of modified standards

  3. Modular product design which enables a quick combination to meet the customer’s power demand

  4. The ability to create a complete and competitive product portfolio

  5. Quickly and closely respond to customer demands

  6. Quality that meets customer expectations

How it works
FSP Group UK 5G CRPS power supply unit grid background

CRPS PSU
FM Series (AC Input)
FN Series (AC Input & NEBs)
(Data Center & Telecom)

FM/FN Series are the redundant power supply module with AC Input base on CRPS 2.0 and NEBS standard. The power supply comes to offer the total power capacity up to 2000 Watts, and provides PMbus features, which makes it to be able communicate with motherboard. In addition, the power supply is ideally the best choice for datacenter, workstation, communication or any other automation applications to use. The product also complies with the latest safety and EMC standards, which is perfectly to meet various regulations worldwide.

FSP550-20FM

FSP550-20FM 550W Platinum CRPS power supply unit module for communication and optical server

  • 80 PLUS Platinum - 550W CRPS PSU

  • 550/800/1200/1300/1600/2000W/2400W

  • Air Flow Out

  • Low iTHD

  • Working temperature: 0 to 55°C

  • Design for 5,000 meters above sea level

  • Support OCP, OTP and OVP circuit protection

  • Short circuit protection on all outputs

  • Resettable power shut down

  • MTBF: 250K hours of continuous operation at 45°C, 75% output load

FSP550-20FN

FSP550-20FN 550W Platinum CRPS power supply unit module for communication and optical server

  • 80 PLUS Platinum - 550W CRPS PSU

  • Fully complied with NEBS standard

  • 550/800W

  • Low iTHD

  • Working temperature: 0 to 55°C

  • Design for 5,000 meters above sea level

  • Support OCP, OTP and OVP circuit protection

  • Short circuit protection on all outputs

  • Resettable power shut down

  • MTBF: 250K hours of continuous operation at 45°C, 75% output load

FSP550-29FM

FSP550-29FM 550W Platinum CRPS power supply unit module for communication and optical server

  • 80 PLUS Platinum - 550W CRPS PSU

  • 550/800/1200/1300/1600W

  • Air Flow In

  • Low iTHD

  • Working temperature: 0 to 55°C

  • Design for 5,000 meters above sea level

  • Support OCP, OTP and OVP circuit protection

  • Short circuit protection on all outputs

  • Resettable power shut down

  • MTBF: 250K hours of continuous operation at 45°C, 75% output load

FSP550-50FS

  • 80 PLUS Platinum - 550W CRPS PSU with 2U Chassis

  • Fully complied with NEBS standard

  • 550/800/1200W

  • Remarkable power density

  • Excellent redundant PSU efficiency

  • Operating altitude complies with 5Km certification

  • Well working performance at 50℃ (24 house running)

  • Low ripple and noise

  • Support OTP, OVP, OCP and SCP circuit protection

  • Complies with FCC, CB, TUV, CE and CCC certification or declaration requirement

  • Compliant with EN62368 , replacing FSP550-50ERS,

FSP Group UK CRPS PSU for 5G application

CRPS PSU
FL Series (DC -48V Input)
(Telecom Application)

FL Series is a redundant power supply module with -48V DC Input base on CRPS 2.0. Support the reversed Air Flow and Screw Terminal Type. The power supply comes to offer the total power capacity up to 1300 Watts, and provides PMbus features, which makes it to be able communicate with motherboard. In addition, the power supply is ideally the best choice for datacenter, workstation, communication or any other automation applications to use. The product also complies with the latest safety and EMC standards, which is perfectly to meet various regulations worldwide.

FSP550-20FL

FSP550-20FL 550W Platinum CRPS power supply unit module for communication and optical server

FSP550-29FL

FSP550-29FL 550W Platinum CRPS power supply unit module for communication and optical server

FSP550-20FL-T

FSP550-20FL-T 550W Platinum CRPS power supply unit module for communication and optical server

  • 80 PLUS Platinum - 550W CRPS PSU

  • 550/800/1300W

  • Air Flow Out

  • Working temperature: 0 to 55°C

  • Design for 5,000 meters above sea level

  • Support OCP, OTP and OVP circuit protection

  • Short circuit protection on all outputs

  • Resettable power shut down

  • MTBF: 250K hours of continuous operation at 45°C, 75% output load

  • 80 PLUS Platinum - 550W CRPS PSU

  • 550/800W

  • Air Flow In

  • Working temperature: 0 to 55°C

  • Design for 5,000 meters above sea level

  • Support OCP, OTP and OVP circuit protection

  • Short circuit protection on all outputs

  • Resettable power shut down

  • MTBF: 250K hours of continuous operation at 45°C, 75% output load

  • 80 PLUS Platinum - 550W CRPS PSU

  • 550/800W

  • Air Flow Out

  • Screw Terminal Type

  • Working temperature: 0 to 55°C

  • Design for 5,000 meters above sea level

  • Support OCP, OTP and OVP circuit protection

  • Short circuit protection on all outputs

  • Resettable power shut down

  • MTBF: 250K hours of continuous operation at 45°C, 75% output load

FSP Group UK CRPS PSU for 5G application

CRPS PSU
FH Series (DC 336V & AC 227V Input)
(New Data Center)

FH Series is a redundant power supply module with DC 336V & 227V Input base on CRPS 2.0 standard. The power supply comes to offer the total power capacity up to 550 Watts, and provides PMbus features, which makes it to be able communicate with motherboard. In addition, the power supply is ideally the best choice for new generation datacenter applications to use. The product also complies with the latest safety and EMC standards, which is perfectly to meet various regulations worldwide.

FSP550-20FH

  • 80 PLUS Platinum - 550W CRPS PSU

  • 550/800/1200/1300/1600W

  • Air Flow Out

  • Support DC & AC Input

  • Low iTHD

  • Working temperature: 0 to 55°C

  • Design for 5,000 meters above sea level

  • Support OCP, OTP and OVP circuit protection

  • Short circuit protection on all outputs

  • Resettable power shut down

  • MTBF: 250K hours of continuous operation at 45°C, 75% output load

FSP550-20FH 550W Platinum CRPS power supply unit module for communication and optical server

CRPS PSU - Power Distribution Board

FSP CRPS Power Supply Unit - Power Distribution Board.png

FSP Group has developed the CRPS product line over the years with a complete product range of 550W~3000W. CRPS’s digital power supply design and component packaging, in combination with software and firmware R&D outcomes, leads to efficiency in excess of 96%, with 80 PLUS Platinum or 80 PLUS Titanium certification. The above models are the Power Distribution Board for CRPS PSU which can provide fully modular cable management.



In addition to the high efficiency, high density, and digitalized design, FSP Group’s CRPS product line also has the following product features:

  • 80 PLUS Platinum or 80 PLUS Titanium conversion efficiency certification

  • In-line with the latest CRPS design specifications

  • Meet PMBus design specifications

  • Support HVDC (240V) input

  • Support Cold Redundancy
